The -6dB Line Pad will reduce distortion and increase headroom in the audio path when the level
from the multitrack recorder return is hot enough to overload the Line Input
Illuminates when engaged
COMP LRG (Compressor to Large Fader): Moves the 200 slot processor into the Large Fader path
• The lower 200 slot is routed to the Small Fader path by default
• Will engage on all channels when the COMP LRG button is engaged in the Master Section
• Illuminates when engaged
NOTE: Engaging the COMP BYP button in the Master Section will bypass the lower 200 slot
(COMP) on all channels console-wide.
PAN: This is the pan pot control for the Large Fader path
-3.5dB pan law
Left/Right panning to stereo Program Buses A, B, and C
Odd/Even panning to Multitrack Buses 1-24
The LG PAN button in the 624 Bus Assignment module must be engaged for the pan-pot to
work
SAFE: Activates the Safe mode for the Large Fader path
The SAFE button protects the Large Fader from being muted when the Solo-In-Place function
is active and another channel is soloed
Protects from global changes to channel input source
Illuminates when engaged
Ø (Phase Reverse): Inserts a polarity inverter into the Large Fader path
Illuminates when engaged
INS (Insert): Activates the Large Fader path Insert Return
Insert Send is fed from the output of the 500 Series EQ slot
Insert Send is always active
Insert Return is located pre the Large Fader
The Insert Return is active only when the INS button is engaged
Controlled by automation
Illuminates when engaged
FILT (Filter): Inserts a high-pass filter in the Large Fader path
2
nd
order filter: 12dB/8va slope
Sweepable 40Hz-600Hz
Illuminates when engaged
SOLO: Activates the selected solo function for the Large Fader path. The following solo functions may
be selected via the Master Section:
Pre-fader Listen (PFL): Non-destructive, mono
Pre-EQ and Insert Listen (PFL2): Non-destructive, mono
After Fader Listen (AFL): Non-destructive, panned
Solo-In-Place (SIP): Destructive, panned, post-fader
Illuminates in yellow when engaged
NOTE: AFL is the default solo mode.
MUTE: Cuts the Large Fader path signal
The MUTE button is the on/off switch for the Large Fader audio path
Can be engaged by Solo-In-Place solos
Controlled by automation
Illuminates in red when engaged
