DIRECT OUTPUT: Channel Direct Output (as assigned)
Fed post-fader from the Large Fader by default
Half-normalled to the MULTITRACK INPUT
• Outputs split if patched
MULTITRACK INPUT: Connection to multitrack recorder inputs
Half-normalled from the DIRECT OUTPUT
Breaking input: Inserted patch cord will replace normalled
connection
NOTE: The multitrack recorder may alternately be fed from the Multitrack Buses by patching the
BUS OUTPUT patch points to the MULTITRACK INPUT patch points.
