Fit the needle cage.
•
Install the clutch gear, making it mesh
with the oil/water pump control gear
TURN THE CLUTCH GEAR COLLAR TOWARD THE
CLUTCH BELL.
•
Insert the clutch bell, making it engage
with the engine pinion
•
Fit the shim washer.
TUONO V4 R a-PRC ABS Engine
ENG - 285
