APRILIA TUONO V4 R a-PRC ABS User Manual

CENTRAL ELECTRICAL SYSTEM
pos. Description Type Quantity Torque Notes
1 Upper Silentblock nut, demand sen-
sor mounting bracket
M6 1 5 Nm (3.69 lb ft) -
2 Demand sensor fixing screw to
mounting plate
SWP 4.9 4 1.2 Nm (0.88 lb ft) -
Components arrangement
key:
TUONO V4 R a-PRC ABS Electrical system
ELE SYS - 95
