1. Side stand sensor
2. Fuel pump
3. Instrument panel
4. Left hand switch
5. Right hand switch
6. Water Temperature Sensor
7. Cooling fans
8. Upper injectors
9. Air temperature sensor
10.Lower injectors
11.Air pressure sensor
12.Exhaust valve
13.Lambda probe
14.Speed sensor
15.Headlamp
16.Rear turn indicators
17.Fall sensor (if fitted)
18.Horn
19.Voltage regulator
20.Battery
21.Auxiliary fuses
22.Control unit
23.Throttle grip position sensor
24.Alternator
25.Coils
26.Timing sensor
27.Starter motor
28.Oil pressure sensor
29.Inertia sensor platform
30.Quick Shift
31.Front tone wheel sensor
32.a-PRC controls
33.ABS control unit
THE IDENTIFICATION OF THE RELAY CANNOT BE CARRIED OUT JUST ON THE BASIS OF THE
INDICATIONS BELOW: IN ANY EVENT IT SHOULD OCCUR WITH THE IDENTIFICATION OF THE
COLOUR OF THE RELAY CABLES.
Electrical system TUONO V4 R a-PRC ABS
ELE SYS - 96
