APRILIA TUONO V4 R a-PRC ABS User Manual

RELAY LAYOUT
Component position
in the electrical circuit
diagram
Component name Location on the vehicle
07 Light logic relay Left side of the front support
65 High beam light relay Internal side, left side of the headlamp
31 Start-up relay Under rear tail fairing
16 Protection relay Under the saddle next to the battery, left side
33 Injection relay Under the saddle near the battery, right side
36 Fan control relay In the headstock niche, on the left
22 Recovery logic relay (urgent service) In the niche of the headstock, on the right
Electrical system installation
INTRODUCTION
Scope and applicability
This document aims at defining the cable harness routing in order to achieve the vehicle reliability
targets.
CHASSIS
Materials used and corresponding quantities
The electrical system consists of the following cable harnesses and parts:
•
1 Vehicle cable harness
•
1 Headlamp cable harness
•
1 License plate frame cable harness
•
1 Positive battery cable
•
1 Battery - engine ground cable
•
1 Ignition switch
•
1 Start-up relay
•
4 Relays
•
1 Protection relay
•
1 Horn
•
1 Fall sensor (optional equipment)
•
1 Headlamp
•
1 Taillight
•
1 Instrument panel
•
1 Front right turn indicator
•
1 Front left turn indicator
•
1 Rear right turn indicator
•
1 Rear left turn indicator
•
1 Stand switch
•
1 Exhaust valve actuator
•
1 Oxygen sensor
TUONO V4 R a-PRC ABS Electrical system
ELE SYS - 97
