Level Two Interface
ARM DDI 0363G Copyright © 2006-2011 ARM Limited. All rights reserved. 9-9
ID073015 Non-Confidential
LDRH
Table 9-5 shows the values of ARADDRM, ARBURSTM, ARSIZEM, and ARLENM for a
Non-cacheable
LDRH
from halfwords 0-3 in Strongly-ordered or Device memory.
A load of a halfword from Strongly-ordered or Device memory addresses
0x1
,
0x3
,
0x5
, or
0x7
generates an alignment fault.
LDR or LDM that transfers one register
Table 9-6 shows the values of ARADDRM, ARBURSTM, ARSIZEM, and ARLENM for a
Non-cacheable
LDR
or an
LDM
that transfers one register, (an
LDM
1) in Strongly-ordered or Device
memory.
A load of a word from Strongly-ordered or Device memory addresses
0x1
,
0x2
,
0x3
,
0x5
,
0x6
, or
0x7
generates an alignment fault.
0x4
(byte 4)
0x04
Incr 8-bit 1 data transfer
0x5
(byte 5)
0x05
Incr 8-bit 1 data transfer
0x6
(byte 6)
0x06
Incr 8-bit 1 data transfer
0x7
(byte 7)
0x07
Incr 8-bit 1 data transfer
Table 9-5 LDRH from Strongly-ordered or Device memory
Address[3:0] ARADDRM ARBURSTM ARSIZEM ARLENM
0x0
(halfword 0)
0x00
Incr 16-bit 1 data transfer
0x2
(halfword 1)
0x02
Incr 16-bit 1 data transfer
0x4
(halfword 2)
0x04
Incr 16-bit 1 data transfer
0x6
(halfword 3)
0x06
Incr 16-bit 1 data transfer
Table 9-6 LDR or LDM1 from Strongly-ordered or Device memory
Address[2:0] ARADDRM ARBURSTM ARSIZEM ARLENM
0x0
(word 0)
0x00
Incr 32-bit 1 data transfer
0x4
(word 1)
0x04
Incr 32-bit 1 data transfer
Table 9-4 Non-cacheable LDRB (continued)
Address[2:0] ARADDRM ARBURSTM ARSIZEM ARLENM
