Level Two Interface
ARM DDI 0363G Copyright © 2006-2011 ARM Limited. All rights reserved. 9-10
ID073015 Non-Confidential
LDM that transfers five registers
Table 9-7 shows the values of ARADDRM, ARBURSTM, ARSIZEM, and ARLENM for a
Non-cacheable
LDM that transfers five registers (an LDM 5) in Strongly-ordered or Device memory.
Note
A load-multiple from address 0x1 , 0x2 , 0x3 , 0x5 , 0x6 , 0x7 , 0x9 , 0xA , 0xB , 0xD , 0xE , or 0xF generates
an alignment fault.
Table 9-7 LDM5, Strongly-ordered or Device memory
Address[4:0] ARADDRM ARBURSTM ARSIZEM ARLENM
0x00 (word 0) 0x00 Incr 32-bit 5 data transfers
0x04 (word 1) 0x04 Incr 32-bit 5 data transfers
0x08 (word 2) 0x08 Incr 32-bit 5 data transfers
0x0C (word 3) 0x0C Incr 32-bit 5 data transfers
