Level Two Interface
ARM DDI 0363G Copyright © 2006-2011 ARM Limited. All rights reserved. 9-11
ID073015 Non-Confidential
STRB
Table 9-8 shows the values of AWADDRM, AWBURSTM, AWSIZEM, and AWLENM for
an
STRB
to Strongly-ordered or Device memory over the AXI master port.
STRH
Table 9-9 shows the values of AWADDRM, AWBURSTM, AWSIZEM, and AWLENM for
an
STRH
over the AXI master port to Strongly-ordered or Device memory.
A store of a halfword to Strongly-ordered or Device memory addresses
0x1
,
0x3
,
0x5
, or
0x7
generates an alignment fault.
Table 9-8 STRB to Strongly-ordered or Device memory
Address[4:0] AWADDRM AWBURSTM AWSIZEM AWLENM WSTRBM
0x00
(byte 0)
0x00
Incr 8-bit 1 data transfer b00000001
0x01
(byte 1)
0x01
Incr 8-bit 1 data transfer b00000010
0x02
(byte 2)
0x02
Incr 8-bit 1 data transfer b00000100
0x03
(byte 3)
0x03
Incr 8-bit 1 data transfer b00001000
0x04
(byte 4)
0x04
Incr 8-bit 1 data transfer b00010000
0x05
(byte 5)
0x05
Incr 8-bit 1 data transfer b00100000
0x06
(byte 6)
0x06
Incr 8-bit 1 data transfer b01000000
0x07
(byte 7)
0x07
Incr 8-bit 1 data transfer b10000000
Table 9-9 STRH to Strongly-ordered or Device memory
Address[2:0] AWADDRM AWBURSTM AWSIZEM AWLENM WSTRBM
0x0
(halfword 0)
0x00
Incr 16-bit 1 data transfer b00000011
0x2
(halfword 1)
0x02
Incr 16-bit 1 data transfer b00001100
0x4
(halfword 2)
0x04
Incr 16-bit 1 data transfer b00110000
0x6
(halfword 3)
0x06
Incr 16-bit 1 data transfer b11000000
