ARRI ALEXA Series User Manual

Lens Data System 217
16.7 Lens Data System
The ALEXA M is equipped with a LA-PL-2 lens mount with LDS
contacts. When using a LDS lens, such as Master Primes or LDS Ultra
Primes, the camera reads, displays and records lens metadata.
The LDS screen can be accessed through the menu, which contains an
additional item "LDS". This menu item is only available on the ALEXA
M.
Note: Lens motors and the Lens Data Archive LDA are not supported by the
ALEXA M.

ARRI ALEXA Series Specifications

General

Dynamic Range	14+ stops
Resolution	4.5K (ALEXA LF), 6.5K (ALEXA 65)
Recording Formats	ARRIRAW, Apple ProRes
Lens Mount	PL mount
Viewfinder	Optional EVF (Electronic Viewfinder)
Sensor Size	Super 35 (most models), Large Format (ALEXA LF, ALEXA 65)
ISO Range	EI 160 - EI 3200 (Base ISO 800)
