9.9 RS
The two RS connectors supply external accessories with at least 24 V
power and a combined load of up to 2.2 A (shared with the EXT
connector power out). The sockets also accept an ARRI remote
start/stop trigger.
The connectors are located at the front of the camera on the camera-
right side.
9.10 12 V
The 12 V connector supplies an external accessory with 12 V power and
up to 2.2 A current.
The connector is located at front of the camera on the camera-right
side.
9.11 TC
The TC connector is a 5pin LEMO socket. It accepts and distributes a
Longitudinal Time Code (LTC) signal.
It can be used to
jam-sync the ALEXA's time code to a Clockit, TC Slate or another
camera
transmit the ALEXA's time code to a Clockit, TC Slate or another
camera
tune the frequency of the ALEXA’s crystal oscillator with an
Ambient ACC Clockit Controller
The connector is located at the front of the camera on the camera-right
side.
9.12 AUDIO OUT
The AUDIO OUT is a 3.5mm TRS connector (headphone jack), which
outputs audio fed to the 5-pin XLR AUDIO IN connector with a
maximum power of 2.5 dBm.
The connector is located at the front of the camera on the camera-right
side.
Note: Connecting headphones to the camera while recording can cause a short
audio signal interruption due to static electricity.
