ARRI ALEXA Series User Manual

44 Camera Support
The bridge plate BP-13 is equivalent to the BP-12, but for 15 mm studio
rods.
Note: Make sure bridge plates are tightened firmly with a screwdriver, not the
commonly used coin!
8.7 Bridge Plate adapter BPA-1
The bridge plate adapter BPA-1 can be used to attach a BP-3/BP-5/BP-
8/BP-9 to ALEXA. First attach the BPA-1 to the camera with the two
screws. Then attach the bridge plate to the adaptor with its two screws.
Make sure the screws are tightened firmly with a screwdriver.

ARRI ALEXA Series Specifications

General

Dynamic Range	14+ stops
Resolution	4.5K (ALEXA LF), 6.5K (ALEXA 65)
Recording Formats	ARRIRAW, Apple ProRes
Lens Mount	PL mount
Viewfinder	Optional EVF (Electronic Viewfinder)
Sensor Size	Super 35 (most models), Large Format (ALEXA LF, ALEXA 65)
ISO Range	EI 160 - EI 3200 (Base ISO 800)
