ARRI ALEXA Series User Manual

Center Camera Handle CCH-1 41
Figure 22: ALEXA with EVF-1, VEB-3 and cable KC-151S
8.4 Center Camera Handle CCH-1
The Center Camera Handle CCH-1 is attached to the camera top with
three captive 3mm hex socket head screws (two at the front and one at
the back). Ensure that the CCH-1 is securely fastened before attempting
to lift the camera from it.
Figure 23: Camera with CCH-1, side view

ARRI ALEXA Series Specifications

General

Dynamic Range	14+ stops
Resolution	4.5K (ALEXA LF), 6.5K (ALEXA 65)
Recording Formats	ARRIRAW, Apple ProRes
Lens Mount	PL mount
Viewfinder	Optional EVF (Electronic Viewfinder)
Sensor Size	Super 35 (most models), Large Format (ALEXA LF, ALEXA 65)
ISO Range	EI 160 - EI 3200 (Base ISO 800)
