ARRI ALEXA Series User Manual

Technical Data are subject to change without notice.CAMERA DIMENSIONS – Version 2012-03
ALEXA M
Backend Top Image Plane
Backend Bottom
Optical Center
3 mm
0.12”
15 mm
0.59”
12.6 mm
0.5”
27.1 mm
1.07”
23 mm
0.91”
41.5 mm
1.63”
38.5 mm
1.52”
58.1 mm
2.29”
55 mm
2.17”
40 mm
1.58”
88.8 mm
3.5”
180 mm
7.09”
183 mm
7.2”
230 mm
9.06”
264 mm
10.39”
322.1 mm
12.68”
27 mm
1.06”
27 mm
1.06”
18 mm
1.71”
18 mm
1.71”
40 mm
1.58”
40 mm
1.58”
43 mm
1.7”
43 mm
1.7”
59 mm
2.32”
65.5 mm
2.58”
74.8 mm
2.94”
M4 (4 mm deep)
26.5 mm
1.04”
26.5 mm
1.04”
67 mm
2.64”
49.3 mm
1.94”
35.5 mm
1.4”
35.5 mm
1.4”
UNC 3/8“–16 (10 mm deep)
152.4 mm
6.0”
80 mm
3.15”
72.4 mm
2.85”

ARRI ALEXA Series Specifications

General

Dynamic Range	14+ stops
Resolution	4.5K (ALEXA LF), 6.5K (ALEXA 65)
Recording Formats	ARRIRAW, Apple ProRes
Lens Mount	PL mount
Viewfinder	Optional EVF (Electronic Viewfinder)
Sensor Size	Super 35 (most models), Large Format (ALEXA LF, ALEXA 65)
ISO Range	EI 160 - EI 3200 (Base ISO 800)
