Setup
DualWave Arthroscopy Pump User’s Guide
DFU-0212 Rev. 1 Page 25 of 54
NOTE: The AR-6480 console incorporates a universal AC input power supply. A
voltage selection switch is not required.
4.4 Electromagnetic Compatibility (EMC)
This device has passed testing for EMI/RFI radiation and
susceptibility and EMC compatibility. This device may cause
interference with other devices in the near vicinity if not set up and
used as instructed by Arthrex.
The AR-6480 has been designed to accept EMC from other devices within the
limitations as described in section 13.0.
To determine if the AR-6480 is causing interference with other devices, power the
AC mains power switch [3] OFF and then ON again.
Try to correct the interference by following one or more of these measures:
1. Reorient or relocate the receiving device.
2. Increase the distance between the devices.
3. Connect the device to an outlet on a different circuit than the other
device(s) are connected to.
4. Consult the manufacturer or field service technician for the receiving
device for guidance.
4.5 Basic Setup Procedure for the AR-6480
WARNING!
To ensure that correct pressure monitoring occurs, the pump and operative site
MUST be in the same horizontal plane.
NOTE: Section 5.0, Operation, explains how to use the console.
1. Place the AR-6480 on a flat, dry surface in the same horizontal plane as
the operative site, such as the AR-6481 Arthrex Arthroscopy pump cart.
2. Connect the receiver end of the power cord for the AR-6480 into the AC
mains power socket [14] and the plug end to the facility AC mains
supply.
3. Connect the Synergy System Integration Cable (if Synergy Integration is
used, skip to step 5).
NOTE: For more on Synergy Heads-Up Display, see IFU 950-0052-00.
4. Connect the Shaver Detect cord (if Shaver Detect is desired, otherwise
skip to step 6).
NOTE: For more on Shaver Detect, see section 4.6.
5. Power on the shaver system.
6. Turn on the AR-6480 [3].
