Product Description
DualWave Arthroscopy Pump User’s Guide
DFU-0212 Rev. 1 Page 17 of 54
Figure 7 Outflow Tubing Configuration (AR-6430)
Table 8 Elements of the Outflow Tubing Configuration
Tubing loop for outflow roller
2
2
.
.
5
5
.
.
2
2
Main Pump Tubing Set (AR-6410: Region A)
The Main Pump Tubing Set offers inflow and pressure sensing tubing. If
used alone, the tubing must be completely discarded following each
surgical procedure. From the pump, the tubing is 4 meters (13 ft.) in
length.
NOTE: This User’s Guide assumes that the AR-6410 is used alone or in
combination with the AR-6220, described below. For specific information
about each tubing set, refer to the Directions for Use that are included
with each set or contact your Arthrex representative.
