Product Description
DualWave Arthroscopy Pump User’s Guide
DFU-0212 Rev. 1 Page 16 of 54
Figure 6 Two-Piece Tubing Configuration
Table 7 Elements of the Two-Piece Tubing Configuration
Element
Description
Tubing Set
a
Bag spikes
AR-6215
b
Tubing clamps
AR-6215
AR-6411/AR-6420
AR-6421/AR-6425
c
Green connector
AR-6411/AR-6420
d
Tubing boot
AR-6411/AR-6420
e
Pressure line connector
AR-6411/AR-6420
f
Neoprene tube for sensing pressure
fluctuations
AR-6411/AR-6420
g
Sensor chamber
AR-6411/AR-6420
k
High flow, dual lumen connectors
AR-6411/AR-6420
AR-6421/AR-6425
i
Backflow check valve
AR-6421/AR-6425
