Quick Start
1-3
Reset Button
The reset button is located at the far left of the front panel. It resets all CPU
functions, including communication and network management. It does not
interfere with traffic through the hub.
Interpreting LEDs
The LEDs on the front panel can be thought of as two separate groups:
• Hub-level status (from PWR to Utilization) at the left, and
• Port-level status (Partition and Link/Receive status) at the
right.
The following tables illustrate LED status indications and what they mean.
