Chapter 4
4-2
Table 4-1. AsantéHub LEDs - Normal Status
LED Normal
Condition
Meaning
PWR Green, ON Green: Power is ON.
CPU Green, BLINKING BLINKING: CPU is present and operating
normally.
SNMP Green ON
or OFF
Green: SNMP daughter board is installed.
OFF: no SNMP board installed.
MSG Amber ON
or OFF
Amber: Status messages received; view
messages through AsantéView.
OFF: No status messages received.
UTILIZATION Green/Amber/Red
or OFF
Indicates % of utilization of this hub's
bandwidth.
COLLISION Amber OFF Indicates % of collisions on this hub.
WARNING OFF Red: Warnings present.
OFF: No warnings present.
PARTITION Amber OFF Amber ON: or blinking indicates
partitioning; port is down.
OFF indicates normal port operation.
LINK/RECEIVE Green
ON/BLINKING
ON: Link is present (or Link Integrity test is
disabled).
1
BLINKING: traffic is passing over this port.
OFF: Link is not present.
Port status is not available if Link Integrity
test is disabled.
1
To enable or disable the Link Integrity test, use AsantéView.
