BNC port and ensure that the weight of the cable will not twist
the T-connector into contact with the AUI cable connector.
5. When you connect the hub to the backbone, traffic over the
hub should begin immediately (if the network is in use). You
will see activity on the Link/Receive Uplink LED (this should be
on, indicating the connection through the backbone). The
same activity should be displayed on the Traffic LED on the
rear panel.
Depending on network activity, you may also see activity on
the Partition Uplink LED, Collision or Warning LEDs, Utilization
LEDs, and MSG LEDs. For details, see Chapter 2, “Hardware
Description,” Table 2-1, “LED Status Indications,” and Figure
2–1, “LED Status Indications, Normal Operation.”
