Chapter 2
2-4
H Link/Receive:
14 separate LEDs:
All LEDs: Off Power to unit is off.
H
1
SNMP
2 Green, on No traffic over the SNMP link.
Or, Link Integrity test disabled.
Green, blinking Traffic over the SNMP link.
Or, Link Integrity test disabled.
H
2
Uplink
(and rear panel
TRAFFIC LED)
Green, on No traffic over the uplink.
Or, Link Integrity disabled.
Green, blinking Traffic over the uplink.
H
3
1-12 Green, on Connected, no traffic.
Or, Link Integrity disabled.
Green, blinking Traffic over a front panel port. Speed of
blinking increases with packets/sec.
I Partition:
4 separate LEDs
I
1
SNMP
2 Amber, blinking Hub has autopartioned the SNMP link.
Collisions too high.
Off SNMP link not partitioned.
I
2
Uplink
(and rear panel
PARTITION LED)
Amber, blinking Hub has autopartioned the uplink.
Collisions too high.
Amber, on Operator has partitioned the uplink.
Off Uplink not partitioned.
I
3
1-12 Amber, on AsantéView operator has partitioned this
front panel port.
Amber, blinking Hub has autopartioned this front panel
port. Collisions too high.
Off Front panel port not partitioned.
1
IEEE 802.3 definitions; see AsantéView manual for complete descriptions
2
If SNMP option is not installed, LED is always OFF.
