TD 92639EN
08 December 2012 / Ver. H
Configuration Manual
Ascom d62 DECT Handset
6
2.2.1 Via Chargers
Connect a desktop charger (DC4) or a rack char
ger (CR3) via the Ethernet port to the
network.
The charger is by default configured to connect to th
e network using DHCP. If DHCP is not
used in the network, connect each charger via USB to a PDM Windows Version and
configure a static IP address.
Start the Device Manager.
Place the handset in a charger that is connected to the Device Manager. The handset can
either b
e turned off or
turned on when placing it in the charger. A handset that is turned
off will start up automatically and the battery charging symbol will be displayed.
Figure 2.
Client
IP
Device Manager
Unite module
Figure 2. Configuration of handsets via Device Manager and chargers.
2.2.2 Over-the-Air via IP-DECT
There is no external equipment needed besides Device Manager and IP-DECT. Please proceed
to cha
pter 3 Installation of Handsets on page 8
.
Figure 3.
Client
IPBS
Ascom
IP-DECT
System
IP
Device Manager
Unite module
Figure 3. Configuration of handsets via Device Manager and over-the-air.
