ASCOM d63 User Manual

TD 93119EN
28 June 2016 / Ver. PA5
User Manual
Ascom d63 DECT Handset
65
Activate Profile
1 Enter the menu by pressing the “Menu” Soft ke
y, or the confirmation button on the
Navigation key.
2 Select
in the menu.
3 Select profile from list.
When a profile is activated, the icon
and the name of the profile are displayed in idle
mode.
Delete Profile
1 Enter the menu by pressing the “Menu” Soft ke
y, or the confirmation button on the
Navigation key.
2 Select
in the menu.
3 Select profile from list.
4 Press "More".
5 Select "Delete" from menu.
6 Press "Select".
7 Press "Yes" to confirm.
Edit Profile
1 Enter the menu by pressing the “Menu” Soft ke
y, or the confirmation button on the
Navigation key.
2 Select
in the menu.
3 Select the profile to edited.
4 Press "More" and then select "Edit".
5 Following options can be performed:
• Edit the wanted setting by marking it and
then press "Edit".
• Add additional settings by pressing "More"
and then select "Add setting" or
"Import from".
• Remove a setting by marking it and then select More > Remove setting.
6 If needed, mark the added settings and press "Edit" to make the
changes.
8.7 Contacts
The handset has a phonebook with 250 entries where the user can add, delete, and edit
names and numbers. The phonebook lists all names in alphabetical order, where three
numbers can be added for each contact; work number, mobile number, and other number.
In addition, a company phonebook with up to 1000 entries can be downloaded to the
handset via the WinPDM/Device
Manager. The company phonebook name and numbers can
not be edited or deleted by the user. The phonebook lists all names in alphabetical order.
The local and company phonebook appears in the same list but the company names are
indicated by an icon
in front of the name. The contact only includes work numbers. See
5.3.9 Dial a Number from t
he Company Phonebook on page 27 for more information.
A central phonebook can also be accessed, see 5.3.8 Dial a Name from the Central
Phonebook on
page 27. This feature is a system dependent feature.
TIP: When searching for a contact, the input language can be temporarily changed by long
pres
sing
. This can be used to temporarily access characters in a foreign language.

ASCOM d63 Specifications

General

Resolution	240 x 320 pixels
Messaging	SMS
Bluetooth	Yes
Wi-Fi	No
Loudspeaker	Yes
3.5mm jack	No
Operating Temperature	-10°C to +55°C
Storage Temperature	-20°C to +60°C
Display size	2.4 inches
Keypad	Physical keys
Battery	Li-Ion
Display type	TFT LCD
Humidity	Up to 95% RH non-condensing
