TD 92579EN
15 February 2012 / Ver. H
Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
103
8.6.4 Session Timer (initial value)
If set, a keep-alive mechanism will be
used to detect if a call is still valid as defined by rfc
4028. This is normally handled by the IP-PBX and then not necessary to be defined here.
1 Select VoIP > SIP.
2 To enable, enter a time (sec.) in the
"(Session Timer initial value)" field.
3 Click "OK".
8.7 UNITE
8.7.1 Configure Messaging
Note: Th
e Unite CM support for the below functions is depending on the Unite CM
software version.
If an IMS3/Unite CM is to be used in the
IP-DECT system, enter the IP address following
the steps below.
1 Select UNITE > SMS.
NOTE: To access the SMS tab, the Master mode has to be activated, see 8.5.13
Select Mode o
n page 94.
2 Enter the address to
the IMS3/Unite CM in the IP Address text field.
3 Click "OK".
If Multicast is to be
used, do as follows:
1 Select UNITE > SMS.
NOTE: To access the SMS tab, the Master mode has to be activated, see 8.5.13
Select Mode o
n page 94.
2 Select the Multicast checkbox.
NOTES: a) The Multicast groups are created in the
ESS, refer to Installation
and Operation Manual, Enhanced System Services, TD 92253GB.
b) In a Multiple Master System all users to
be reached by a Multicast
message must be assigned to the PARI Master.
c) In order to support Multicast messaging the IMS3 must be
insta
lled with version 2.62 or later
d)
To support multicast only Worf (KRCNB 30x , BS3x0 and DB1)
RFPs shall be used.
3 Click "OK".
If the communication between the Ma
ster and the IMS3/Unite CM should be encrypted,
do as follows:
1 Select UNITE > SMS.
Note: To access the SMS tab, the Master mode has to be activated,
see 8.5.13
Select Mode o
n page 94.
