TD 92579EN
15 February 2012 / Ver. H
Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
109
6 Click "Move".
Existing RFPI on the new Radio is replaced by th
e broken Radio’s RFPI. The new
Radio’s RFPI is now released and can be reused. All other RFPIs in use are not
affected. The broken Radio will be deleted from the Static Registrations section.
8.10.2 RFPs
This section only applies to the IPBL.
Inf
ormation about the DECT devices connected to the IPBL. For explanation on the
information, see the table below.
1 Select Device Overview > RFPs.
2 Click the applicable port to open th
e RFP details pop-up window.
Figure 25. å
Figure 26.
Port The port used in the IPBL.
Status Current status of the IPBS connected to the IPBL.
Description A short description to help identify the IPBS.
RFPI Identity number.
SW Version The current software version.
Hardware The hardware version.
Boot RFP boot version.
Connected Time The elapsed time since the RFP connected to the IPBL.
Cable Delay The delay caused by the cable.
Tx Error The number of transmitting errors.
Rx Error The number of receiving errors.
3 The following actions are available:
• Click "OK" to save your settings and close the pop-up window.
• Click "Cancel" to close the pop-up window.
• Click "Refresh" to update the information.
• Click "Reset" to reset the RFP.
8.10.3 Sync Ring
This section only applies to the IPBL.
A w
ire map of the synchronization ring is available in the GUI. The identities (IPBL-xx-xx-xx)
of the IPBLs and the position in the ring is displayed. If the ring is broken it is possible to
locate where. Click the IP address to access another IPBL.
1 Select DECT Sync > Sync Ring.
8.10.4 Sync Ports
This section only applies to the IPBL.
Displays the
current status of the synchronization ports.
1 Select DECT Sync > Sync Ports.
Status The current status of the port.
