TD 92579EN
15 February 2012 / Ver. H
Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
136
8.21.5 Performance
It is possible to check different performance parameters. For a description of the
p
arameters, see the table below.
Figure 32.
Parameter Description
CPU Shows CPU utilization
CPU-R Shows utilization of CPU resources allocated by
dif
ferent tasks
MEM Shows memory utilization
Concurrent calls Shows the number of ongoing calls
Temperature (only for IPBL) Shows the temperature of the cabinet
Voltage (only for IPBL) Shows the power supply voltage level
Current (only for IPBL) Shows the power supply current consumption
1 Select Diagnostics > Performance
2 Select the checkbox(es) for the d
esired performance statistics.
3 Click "OK".
4 One window shows statistics for the last 24 hours. The
maximum possible value is
displayed in the top-left corner. Click the left or right arrow buttons to see different
time frames.
8.21.6 Config Show
Under Diagnostics > Config Show, the configuration is displayed as a text output.
Code A unique number that identifies the alarm.
Click the
code to get more detailed information about the
alarm. For a list of possible codes and their
descriptions, see 10.2 Faul
t Code Descriptions on
page 142.
Severity It has three possible states:
• Critical - Immediate action is
r
equired. It is displayed, for
example, if a managed object goes
out of service.
• Major - Urgent action is required. It
is
displayed, for example, if the
capability of the managed object is
severely degraded.
• Indeterminate - Level of severity
can
not be determined
Remote The IP Address of the object that r
eported the alarm.
Click the IP address to access the object.
Source The software module that reported the alarm.
T
ogether with the code it uniquely identifies an
alarm.
Description A textual description of the alarm.
