114 G12 OEM Board & Sensor Reference Manual
The general format for the set commands controlling the output of raw messages
is as follows:
$PASHS,RAW,s1,c1,s2,[f1]
In this context, set commands are used to enable the output of raw data messages
at regular intervals or to disable output of raw messages, where s1 is a three
character message identifier (SNV, MBN, CT1, etc.), c1 is the port designator for
message output, s2 is ON or OFF, and f1 is the optional numeric output interval
setting supporting a range of 0.05 to 999 seconds, depending on the measurement
update rate option installed.
If the output is set without a period, f, and the period set by the $PASHS,RCI command is issued
after individual RAW message output periods have been set, all individual message periods will be
reset to the RCI output period setting.
Before using 10 Hz or 20 Hz update rate, you must issue the $PASHS,POP command.
$PASHS,RCI Set recording interval 134
$PASHS,RAW Set raw data parameters 109
$PASHS,SIT Set site name 136
COMBINED RAW DATA
$PASHS,RAW,CT1 Enable/disable combined measurement/position data message format 1 117
$PASHQ,CT1 Query combined raw data in CT1 format data structure 117
$PASHR,CT1 CT1 response message 117
$PASHS,RAW,CT2 Enable/disables combined measurement/position data message format 2 118
$PASHQ,CT2 Query combined raw data in CT2 format data structure 118
$PASHR,CT2 CT2 response message 119
$PASHS,RAW,CT3 Enable/disables combined measurement/position data message format 3 120
$PASHQ,CT3 Query combined raw data in CT3 format data structure 120
$PASHR,CT3 CT3 response message 120
$PASHS,RAW,MCM Set Missile Applications Condensed Measurements data structure 128
$PASHQ,MCM Query Missile Applications Condensed Measurements data structure 129
Response msg MACM response message structure 129
Table 4.55. Raw Data Commands (Continued)
Command Description Page
G12RevD.book Page 114 Tuesday, April 2, 2002 4:33 PM
