TECHNICIANS' manual74 of 104
no more milk residue is dispensed.
8.8.7 Cleaning the drip tray
Periodically clean the drip tray as follows:
• Unscrew 2 screws (B) from the upper grille (A).
• Lift the upper grille (A) and disconnect the cup warmer
heating element’s power supply connector (D) and the
temperature probe connection (C).
• Clean the rear drip tray (E) - secured to the machine - with
a cloth dampened in lukewarm water.
• Unscrew the screws (F) by detaching the front drip tray (G)
from the grill (A).
• Clean the front drip tray (G) with a cloth dampened in
lukewarm water.
• Once the maintenance work has been carried out, reposi-
tion all the components in their original location by car-
rying out the steps in reverse order. Restore the electrical
mains connections of the cup warmer heating element
and the temperature probe.
B
G
A B
D
C
A
E
F
F
