3.1.3. Connection to the Asycube with the Plugin .NET and configuration
with Asyril HMI
In this integration mode, the integrator uses the Asycube HMI (installed on a computer, the
same as the integrator system or another one) to configure the Asycube and communicates
with the Asycube from his own system in order to execute the vibrations by using the
Asycube Plugin .NET. This Plugin simplifies the development and allows to export and import
the same recipe files as in the Asycube HMI.
PC
Controller
.dll
Asycube HMI
.fconf
.fseq
CAMERA
ROBOT
.dll
ASYCUBE
Firmware
LEVEL
TASKS
Asycube
 Generation and synchronization of the desired vibration
 Execute sequences
 Save and reload 25 vibration sets (26 for the reload)
 Save and reload 25 sequences (26 for the reload)
 Activation of the outputs and backlight
 Choice/Management of the optimal sequence based on the vision
feedback
Asycube Plugin
.NET
 Communication with the Asycube (access to the parameters of the
vibrations and sequences, vibrations and sequences execution, etc)
 Treatment of the recipe (read/write parameters)
Asycube HMI
 Configuration and optimization of the feeding (vibration) parameters
 Configuration and optimization of the sequences
Integrator
 Synchronization of the feeder and the machine
 Recipe management (memorize vibration set ID and sequence ID for
each component).
Table 3-3: Integration mode: Asycube with Plugin .NET and HMI
