Programming Guide
© Copyright Asyril S.A.
000.101.572
Version : A1
23/83
Address
Parameters
Vibration
Units
Range
314
Waveform 2
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
316
Amplitude 3
[%]
0 to 100 %
318
Frequency 3
[Hz]
0 to 250 Hz
320
Waveform 3
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
940
Duration
[ms]
0 to 30’000 ms
324
Amplitude 1
Platform "B"
[%]
0 to 100 %
326
Frequency 1
[Hz]
0 to 250 Hz
328
Phase 1
[°deg.]
0 to 359 degrees
330
Waveform 1
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
332
Amplitude 2
[%]
0 to 100 %
334
Frequency 2
[Hz]
0 to 250 Hz
336
Phase 2
[°deg.]
0 to 359 degrees
338
Waveform 2
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
340
Amplitude 3
[%]
0 to 100 %
342
Frequency 3
[Hz]
0 to 250 Hz
344
Waveform 3
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
942
Duration
[ms]
0 to 30’000 ms
Table 4-3: platform vibrations parameters A and B for the Asycube 50 and Asycube 80
4.2.2. For the Asycube 240 and Asycube 530
The Table 4-4 shows the formula to get the addresses of the platform vibrations parameters,
while the Table 3-1 presents the specific addresses for the vibrations A and B. These
parameters are set from address range 300 to 1962.
Address
Parameters
Vibration
Units
Range
300+64*n
Amplitude 1
Platform "n"
A: n=0,
B: n=1,
…
Z: n=25
[%]
0 to 100 %
302+64*n
Frequency 1
[Hz]
0 to 250 Hz
304+64*n
Phase 1
[°deg.]
0 to 359 degrees
306+64*n
Waveform 1
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
310+64*n
Amplitude 2
[%]
0 to 100 %
312+64*n
Frequency 2
[Hz]
0 to 250 Hz
314+64*n
Phase 2
[°deg.]
0 to 359 degrees
