4.3.2. Outputs activations (Asycube 240 and Asycube 530)
The Table 4-8 shows the formula to get the addresses of the outputs activations parameters,
while the presents the specific addresses for the outputs activations A and B. These
parameters are set from address range 2000 to 2414.
Address
Parameters
Activation
Units
Range
2000+16*n
Toggle output 1
Outputs "n"
A: n=0,
B: n=1,
…
Z: n=25
[bool]
0=no signal, 1=signal
2002+16*n
Amplitude output 1
[%]
0 to 100% (0 to 10V)
2004+16*n
Toggle output 2
[bool]
0=no signal, 1=signal
2006+16*n
Amplitude output 2
[%]
0 to 100% (0 to 10V)
2014+16*n
Duration
[ms]
0 to 30’000 ms
Table 4-8: Generic addressing of the outputs activations parameters for the Asycube
240 and Asycube 530
Address
Parameters
Activation
Units
Range
2000
Toggle output 1
Outputs "A"
[bool]
0=no signal, 1=signal
2002
Amplitude output 1
[%]
0 to 100% (0 to 10V)
2004
Toggle output 2
[bool]
0=no signal, 1=signal
2006
Amplitude output 2
[%]
0 to 100% (0 to 10V)
2014
Duration
[ms]
0 to 30’000 ms
2016
Toggle output 1
Outputs "B"
[bool]
0=no signal, 1=signal
2018
Amplitude output 1
[%]
0 to 100% (0 to 10V)
2020
Toggle output 2
[bool]
0=no signal, 1=signal
2022
Amplitude output 2
[%]
0 to 100% (0 to 10V)
2030
Duration
[ms]
0 to 30’000 ms
Table 4-9: outputs activations parameters A and B for the Asycube 240 and Asycube
530
