4.3. Hopper Vibrations or Outputs Activations
This section presents the hopper vibration parameters for the Asycubes 50 and 80 and the
output activations parameters for the Asycubes 240 and 530.
4.3.1. Hopper vibrations (Asycube 50 and Asycube 80)
The Table 4-6 shows the formula to get the addresses of the hopper vibrations parameters,
while the Table 4-7 presents the specific addresses for the vibrations A and B. These
parameters are set from address range 1000 to 1204 and 1240 to 1290.
Address
Parameters
Vibration
Units
Range
1000+8*n
Amplitude
Bulk "n"
A: n=0,
B: n=1,
…
Z: n=25
[%]
0 to 100%
1002+8*n
Frequency
[Hz]
0 to 250 Hz
1004+8*n
Figure
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
1240+2*n
Duration
[ms]
0 to 30’000 ms
Table 4-6: Generic addressing of the hopper vibrations parameters for the Asycube 50
and Asycube 80
Address
Parameters
Vibration
Units
Range
1000
Amplitude
Bulk "A"
[%]
0 to 100%
1002
Frequency
[Hz]
0 to 250 Hz
1004
Figure
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
1240
Duration
[ms]
0 to 30’000 ms
1008
Amplitude
Bulk "B"
[%]
0 to 100%
1010
Frequency
[Hz]
0 to 250 Hz
1012
Figure
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
1242
Duration
[ms]
0 to 30’000 ms
Table 4-7: hopper vibrations parameters A and B for the Asycube 50 and Asycube 80
