Programming Guide
© Copyright Asyril S.A.
000.101.572
Version : A1
72/83
6.3.4. Recipe Write Holding Registers (Write-only zone, offset=1536)
The Recipe Write Holding Registers presented in Table 6-4 are used to set the configuration values of the Asycube vibrations and sequences.
The Holding Registers highlighted in bold are triggers that start an action or change a value.
Address
(decimal)
Holding Register name
Read/
Write
Data Range
Comments
1536+0
HR_PLATFORM_PARAMETERS_WRITE_TRIG
W
0 or 1
A rising edge trigs the write of the platform vibration Holding Registers
HR_PLATFORM_VIBRATION_AMPL1 (Address 1536+2) to
HR_PLATFORM_VIBRATION_DURATION0 (Address 1536+18) to the vibration
parameters (Section 4.2) for the identifier
HR_PLATFORM_PARAMETERS_WRITE_ID.
1536+1
HR_PLATFORM_PARAMETERS_WRITE_ID
W
0 to 25
The platform vibration write trigged with
HR_PLATFORM_PARAMETERS_WRITE_TRIG uses this Holding Register to
save the values at the given identifier, where 0 = ‘A’, 1 = ‘B’, …
1536+2
HR_PLATFORM_VIBRATION_AMPL1
W
This value is written to the corresponding parameter in Section 4.2.
1536+3
HR_PLATFORM_VIBRATION_FREQ1
W
This value is written to the corresponding parameter in Section 4.2.
1536+4
HR_PLATFORM_VIBRATION_PHASE1
W
This value is written to the corresponding parameter in Section 4.2.
1536+5
HR_PLATFORM_VIBRATION_WAVEFORM1
W
This value is written to the corresponding parameter in Section 4.2.
1536+6
HR_PLATFORM_VIBRATION_AMPL2
W
This value is written to the corresponding parameter in Section 4.2.
1536+7
HR_PLATFORM_VIBRATION_FREQ2
W
This value is written to the corresponding parameter in Section 4.2.
1536+8
HR_PLATFORM_VIBRATION_PHASE2
W
This value is written to the corresponding parameter in Section 4.2.
1536+9
HR_PLATFORM_VIBRATION_WAVEFORM2
W
This value is written to the corresponding parameter in Section 4.2.
