Programming Guide
© Copyright Asyril S.A.
000.101.572
Version : A1
24/83
Address
Parameters
Vibration
Units
Range
316+64*n
Waveform 2
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
320+64*n
Amplitude 3
[%]
0 to 100 %
322+64*n
Frequency 3
[Hz]
0 to 250 Hz
324+64*n
Phase 3
[°deg.]
0 to 359 degrees
326+64*n
Waveform 3
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
330+64*n
Amplitude 4
[%]
0 to 100 %
332+64*n
Frequency 4
[Hz]
0 to 250 Hz
334+64*n
Phase 4
[°deg.]
0 to 359 degrees
336+64*n
Waveform 4
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
362+64*n
Duration
[ms]
0 to 30’000 ms
Table 4-4: Generic addressing of the platform vibrations parameters for the Asycube
240 and Asycube 530
Address
Parameters
Vibration
Units
Range
300
Amplitude 1
Platform "A"
[%]
0 to 100 %
302
Frequency 1
[Hz]
0 to 250 Hz
304
Phase 1
[°deg.]
0 to 359 degrees
306
Waveform 1
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
310
Amplitude 2
[%]
0 to 100 %
312
Frequency 2
[Hz]
0 to 250 Hz
314
Phase 2
[°deg.]
0 to 359 degrees
316
Waveform 2
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
320
Amplitude 3
[%]
0 to 100 %
322
Frequency 3
[Hz]
0 to 250 Hz
324
Phase 3
[°deg.]
0 to 359 degrees
326
Waveform 3
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
330
Amplitude 4
[%]
0 to 100 %
332
Frequency 4
[Hz]
0 to 250 Hz
334
Phase 4
[°deg.]
0 to 359 degrees
336
Waveform 4
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
362
Duration
[ms]
0 to 30’000 ms
364
Amplitude 1
Platform "B"
[%]
0 to 100 %
366
Frequency 1
[Hz]
0 to 250 Hz
368
Phase 1
[°deg.]
0 to 359 degrees
370
Waveform 1
[0..3]
0=no signal, 1=sinus, 2=rp up, 3= rp dn
