Asyril Asycube 530 Programming Guide

Asycube - Asyril SA
Programming Guide
© Copyright Asyril S.A.
000.101.572
Version : A1
21/83
Address
Parameters
Command
Comment
110
Vibration Set ID
**
Selected Vibration Set ID [1...26]
112
Sequence ID
**
Selected Sequence ID [1...26]
…
130
Sequence ID Input 1
Sequence ID [1...26]
132
Sequence ID Input 2
Sequence ID [1...26]
…
144
UART1 rx timeout Ethernet
*
Default: 1'000 [ms]
148
UART1 tx timeout Ethernet
*
Default: 2 [ms]
…
152
Backlight timeout
**
0= disable timeout function
30 = 30 sec with PWM 100%, 60 sec with
PWM 50%, etc.
0 for Asycubes 240 and 530 backlight
because there is no risk to keep it switched
on permanently.
…
158
Gain amplitude actuator 1
*
(int) [2.55]
160
Gain amplitude actuator 2
*
(int) [2.55]
162
Gain amplitude actuator 3
*
(int) [2.55]
164
Gain amplitude actuator 4
*
(int) [2.55]
166
Offset amplitude actuator 1
*
(int) +/- n 1/256
168
Offset amplitude actuator 2
*
(int) +/- n 1/256
170
Offset amplitude actuator 3
*
(int) +/- n 1/256
172
Offset amplitude actuator 4
*
(int) +/- n 1/256
174
Offset frequency actuator 1
*
(int) +/- n 0.25 Hz
176
Offset frequency actuator 2
*
(int) +/- n 0.25 Hz
178
Offset frequency actuator 3
*
(int) +/- n 0.25 Hz
180
Offset frequency actuator 4
*
(int) +/- n 0.25 Hz
182
Gain amplitude output 1
*
(int) [2.55]
184
Gain amplitude output 2
*
(int) [2.55]
186
Offset amplitude output 1
*
(int) +/- n 1/256
188
Offset amplitude output 2
*
(int) +/- n 1/256
190
Output 1 logic
*
0 : logic positive / 1 : logic negative
192
Output 2 logic
*
0 : logic positive / 1 : logic negative
194
Input 1 logic
*
0 : logic positive / 1 : logic negative
196
Input 2 logic
*
0 : logic positive / 1 : logic negative
Table 4-1: configuration parameters
