Programming Guide
© Copyright Asyril S.A.
000.101.572
Version : A1
68/83
Address
(decimal)
Holding Register name
Read/
Write
Data Range
Comments
128+13
HR_PLATFORM_VIBRATION_A_FREQ4
R
Direct read access to corresponding parameter in Section 4.2.
N/A for the Asycube 50 and 80.
128+14
HR_PLATFORM_VIBRATION_A_PHASE4
R
Direct read access to corresponding parameter in Section 4.2.
N/A for the Asycube 50 and 80.
128+15
HR_PLATFORM_VIBRATION_A_WAVEFORM4
R
Direct read access to corresponding parameter in Section 4.2.
N/A for the Asycube 50 and 80.
128+16
HR_PLATFORM_VIBRATION_A_DURATION
R
Direct read access to corresponding parameter in Section 4.2.
128+17
to
128+441
HR_PLATFORM_VIBRATION_B_TO_Z_DATA
R
Direct read access to corresponding parameters in Section 4.2.
The address has to be computed based on the 17 previous parameters (Address
128+0 to 128+16) with the following formula:
Desired_Address = Address_Of_The_Register_For_Vibration_A
+ 17 x Vibration_Identifier, where ‘A’=0, ‘B’=1, …
Example: HR_PLATFORM_VIBRATION_E_WAVEFORM3 =
HR_PLATFORM_VIBRATION_A_WAVEFORM3 + 17 x E = 128+11 + 17 x 4 =
128+79
128+442
HR_HOPPER_A_DIGITAL_OUTPUT1
R
Direct read access to corresponding parameter in Section 4.3.
N/A for the Asycube 50 and 80.
128+443
HR_HOPPER_A_ANALOG_OUTPUT1
R
Direct read access to corresponding parameter in Section 4.3.
N/A for the Asycube 50 and 80.
128+444
HR_HOPPER_A_DIGITAL_OUTPUT2
R
Direct read access to corresponding parameter in Section 4.3.
N/A for the Asycube 50 and 80.
128+445
HR_HOPPER_A_ANALOG_OUTPUT2
R
Direct read access to corresponding parameter in Section 4.3.
N/A for the Asycube 50 and 80.
