Manual, F/T Sensor, Data Acquisition (DAQ) Systems
Document #9620-05-DAQ.indd-20
Pinnacle Park • 1031 Goodworth Drive • Apex, NC 27539 • Tel: 919.772.0115 • Fax: 919.772.8259 • www.ati-ia.com • Email: info@ati-ia.com
68
9.3 9105-IFPSMC Multiple IFPS Box
3rd ANGLE PROJECTION
169.5
104.7
4.8
Transducer 2
Transducer 3
Transducer 6
Transducer 1
See Note 2
Transducer 5
Transducer 4
Front View
142.5 25.3
177.8
17.6
Typ
160
58.9
9.7
Typ
16.5
4.4
Typ
17.8
Typ
8.7
Typ
6.4
Typ
18
36.8
15.2
R
5
Typ
Power Connector
Connector 1 to
External User Equipment
Connector 0 to
External User Equipment
Connector 0
to DAQ Card
Connector 1
to DAQ Card
Rear View
Note 2
Notes:
Six transducer connectors are included, however the number of interface boards
1.
included is model dependent. Versions for 1-6 boards are available.
This feature is reserved for factory use only.
2.
Minimum recommended front-panel clearance is 80mm. Minimum recommended
3.
rear-panel clearance is 150mm.
Rev.
Description
Initiator
Date
04
Updated to show all connector spaces populated.
PPF
7/18/2017
B
1:2
1 1
REVISION
NOTES: UNLESS OTHERWISE
SPECIFIED.
DO NOT SCALE DRAWING.
ALL DIMENSIONS ARE IN
MILLIMETERS.
DRAWN BY:
CHECKED BY:
R. Chambers 2/11/11
D. Mushow 2/15/11
TITLE
SCALE
SIZE
DRAWING NUMBER
PROJECT #
SHEET OF
9230-05-1384
101020-1
04
PROPERTY OF ATI INDUSTRIAL AUTOMATION, INC. NOT TO BE REPRODUCED IN ANY
MANNER EXCEPT ON ORDER OR WITH PRIOR WRITTEN AUTHORIZATION OF ATI.
1031 Goodworth Drive, Apex, NC 27539, USA
Tel: +1.919.772.0115 Email: info@ati-ia.com
Fax: +1.919.772.8259 www.ati-ia.com
ISO 9001 Registered Company
9105-IFPSMC-X
