FlexiROC T35 R/T40 R 9 Angle instruments
120 No: 3171473547.1 en
Sensor calibration menu.
a Feeder tipping angle
b Feed swing
c Aim
d Boom Swing
e Cradle position
e Information on cradle speed
4.
If any value is not 0, it must be reset for the instrument to function correctly.
5.
Use the arrow keys to mark one button at a time and press Enter to reset the value.
6.
Once all values are 0, leave the menu using ESC.
Calibration of the length sensor
The length sensor must be recalibrated as follows each time the CAN-BUS is restarted.
1.
Run the rock drill to its uppermost position.
2.
Run the rock drill down slowly past the calibration sensor.
