FlexiROC T35 R/T40 R 9 Angle instruments
119 No: 3171473547.1 en
D171 Inclination sensor
B172 Length Sensor
1 Switch
2 Adjusting screws
Carefully open the cover and set the DIP switches as illustrated below. The illustration is
also found on the inside of the A1 cabinet door.
DIP switch settings for D170.
DIP switch settings for D171.
Aim device S146
The aim device unit S146 does not require calibration as it is an analogue sensor and not a
part of the CAN-BUS system.
9.1.6 Calibration
n Set the boom so that it is aimed straight ahead, parallel to the boom bracket.
n Set the aim device so that it is aimed straight ahead, i.e. at a 90° angle and parallel to
the boom.
n Use a level to adjust the feed beam to a vertical position both front/back and left/right
n Run the rock drill cradle to the mechanical stop at the top of the feeder.
Once this is done, the system can be calibrated from the "Sensor/Calibration" menu.
1.
Log in to the "Logging in" menu following the instructions under the Settings heading.
2.
Use the arrow keys to mark the button by the "sensor calibration" symbol. Confirm
with Enter to access the "Sensor/Calibration" menu.
3.
A list of the sensors in the angle and drilled length system is displayed in the sensor
calibration menu ("SENSOR/CALIBRATION"). When boom, aim device, feeder and
rock drill cradle are in their respective zero positions in accordance with the conditions
above then the digit values in the menu shall also be 0.
