FlexiROC T35 R/T40 R 5 Controls
34 No: 3171473547.1 en
3 Control panel for pressure and pressure gauges
4 Test connections for the hydraulic circuits
5 Display for diesel engine
6 Electric cabinet
5.1.2 Remote control box
WARNING
Serious injury
Danger of accidental operation
u May cause serious personal injury and damage to property
u The operator must always have an overview of the drill rig and the remote control box
u Always check that the controls are correctly adjusted before operating
u Always deactivate the remote control box when it is not in use
u The remote control box must not be operated from the drill rig when the winch is in use
WARNING
Serious injury
When the remote control box is deactivated then no functions can be controlled
The remote control box is a multi-function box with two levers that change function depend-
ing on the mode set on the remote control box.
!
NOTE: Pay attention to the mode set on the remote control box!
