FlexiROC T35 R/T40 R 6 Operating
79 No: 3171473547.1 en
è
A symbol will light up on the diesel engine display once the remote control box
has been activated.
5.
Press the start button S186 (B) and then (within 5 seconds) press the button (C) for
Suction cup position down (c) and hold for more than one second, then press Suction
cup (C) position up (a) until the engine starts.
!
NOTE: If a fault is indicated on the display for the diesel engine,
turn off the engine and see which symbol is on. Rectify the fault.
6.
Check the hydraulic oil temperature (must be preheated to at least 20 °C (68 °F)).
6.3 Regeneration (Tier 4 Final)
WARNING
Serious injury
Very high exhaust temperatures >600°C
u May cause serious personal injury and damage to property
u Always check that the rig is positioned so that fire or other damage cannot occur when
regeneration is in progress
