FlexiROC T35 R/T40 R 5 Controls
45 No: 3171473547.1 en
9 Percussion pressure gauge
10 Return oil pressure gauge
11 Drill feed pressure gauge
12 Lubrication oil pressure gauge
13 Flushing air pressure gauge
14 Rotation pressure gauge
15 Extra air outlet
5.1.9 Control panel for diesel engine and directional instrument
Control panel for diesel engine and directional instrument
D510 Display for diesel engine and dir-
ectional instrument
S130B N/A
S139 Starter key for diesel engine
a Off
b Ignition
c N/A
P Override DES
S172 Circuit breaker for activating
winch
