FlexiROC T35 R/T40 R 5 Controls
35 No: 3171473547.1 en
Functions
Remote control box.
S100 Circuit breaker Flushing air
a Default: Full flushing air/ Dust collector active
b Default: Reduced flushing air/ Dust collector active
c Flushing air deactivated
S101 Release button
n Rotation and feed cease
n Percussion ceases/ Normal mode
!
NOTE: If the release button has not been reset, it will not be
possible to restart rotation, percussion or feed.
S113 Switch Activate limit position sensors
a Sensors deactivated
c Sensors activated
S119 Switch Upper drill-steel support
a Closed
n The upper drill-steel support opens automatically when the rock drill ap-
proaches it
n Drilling stops automatically
n The upper drill-steel support closes automatically during retraction
b Neutral
n The upper drill-steel support opens automatically when the rock drill ap-
proaches it
n The shank join is automatically released when drilling
n The upper drill-steel support closes automatically during retraction
