FlexiROC T35 R/T40 R 5 Controls
36 No: 3171473547.1 en
c Open
n Drilling stops automatically
S130 Mode selector knob for remote control box
f Adjustment mode while drilling
g Drilling/Shut-down/Preheating
h Positioning/Tramming/Winching
S132 Drill rig stop active
!
NOTE: Works only when radio system is active!
S137 Switch for Tramming speed
a Low tramming speed (high traction)
c High tramming speed (low traction)
S167 Circuit breaker suction hood
a Suction hood up (or engine start)
c Suction hood down (or engine stop)
S169 Key for activating remote control box
Clockwise: Activated
Anticlockwise: Deactivated
S173 Circuit breaker Winching
a Wind in
b Neutral
c Wind out
S174-
S175
Right/Left tramming lever
a Forward
b Neutral
c Reverse
!
NOTE: The speed of the tracks is proportional to the levers, use
the levers carefully.
S176 Switch, left Track oscillation
a Lower front section
b Neutral
c Raise the front
