FlexiROC T35 R/T40 R 5 Controls
37 No: 3171473547.1 en
S177 Switch, right Track oscillation
a Lower front section
b Neutral
c Raise the front
S181 Circuit breaker Dust collector (DCT)
a Dust collector activated
c Dust collector inactivated
S182 Sleeve grippers button
n Sleeve grippers to drill centre
n Sleep grippers to carousel
!
NOTE: For the sleeve grippers to work, the rod handling arms
must be in the drill centre and the rod handling grippers must be
in position "Hard grip".
S186 Horn/Reactivation of remote control box button
S187 Lower drill-steel support
a Closed
b Neutral
c Closed
S189 Engine speed button
n Adjustable speed: In this position, the speed can be adjusted using the poten-
tiometer R189 on the diesel panel (1200 to 2200 rpm)
n Low speed (1500 rpm)
S209 Switch Jack
a Jack up
b Neutral
c Jack down
S260 Left multi-function lever (rod handling and feeder positioning)
S261 Right multi-function lever (drilling and boom positioning)
S445 Switch Track oscillation lock
a Locked track oscillation
c Open track oscillation
S448 Switch Water mist system
a Reduced water mist
b No water mist
