FlexiROC T35 R/T40 R 5 Controls

39 No: 3171473547.1 en

Sector Function

c Drill feed reverse (when percussion active)/ Rapid

feed reverse (when percussion inactive). If low

percussion is activated manually, rapid feed re-

verse can be obtained

d Drill rotation-Self-holding/air

e Rotation right

f Drill feed forwards (self-holding feed percussion

(j))/reduced percussion

g Threading

h Drill feed reverse

i Unthreading

j Self holding for high percussion and feed.

Table16: Sector description.

NOTE: Sequence d - f - j gives automatic collaring. I.e. first drill rotation with flushing

air (d), then low drill feed and low percussion (f). When (j) is then reached self-holding

and an automatic increase to high percussion and high feed are attained after 5

seconds.

CCW Flushing air activated

Low percussion and flushing air activated (if lever

held longer than 0.5 sec)

CW High percussion (No holding)

Table17: Rotation of multi-function lever when no other functions are active

CCW Deactivates drilling (low percussion, rotation,

flushing air and feed)

CW Activates full drilling (high percussion, rotation,

flushing air and high-speed)

Table18: Rotation of multi-function lever when collaring (active low percussion, rotation, flushing air and

low feed)

CCW Activates collaring (low percussion, rotation, flush-

ing air and low feed)

CW Deactivates drilling (percussion, rotation, flushing

air and feed)

Table19: Rotation of multi-function lever when full drilling (high percussion active, rotation, flushing air

and high feed)

CCW Activates low percussion
