FlexiROC T35 R/T40 R 7 Before drilling
96 No: 3171473547.1 en
CAUTION
Risk of injury
Risk of feed beam bending
u To avoid overloading the feeder, do no use the cylinder alone for lowering the boom, or
the cylinder for feed extension individually to place the feeder against the ground
u Do not raise the front section of the track frame from the ground
1.
Put the remote control box in tramming and positioning mode. Knob S103, position
(h).
Remote control box.
2.
Make sure track oscillation is open. Switch S445, position (c).
3.
Set up the drill rig horizontally using track oscillation. Switches S176 and S177.
Correct set up for drilling.
4.
Lock track oscillation once it is in the desired position. Switch S445, position (a).
5.
Lower the jack so it is firmly on the ground without lifting the drill rig. Switch S209, po-
sition (c).
