The Status Bar
The Sta tus bar runs across the bot tom of the workspace. On the right, the
Sta tus bar dis plays the workspace page tabs; on the right are sta tus notes up -
dated as the con trol soft ware op er ates.
The Toolbars
The 2700 se ries con trol soft ware has five toolbars for quick ac cess to pan els
and com mon func tions. The toolbars can “float” at any lo ca tion you place
them on the workspace, or they can be “docked” or at tached to the Menu bar.
Whether docked or float ing, the toolbars ap pear on ev ery workspace page.
The toolbars dis play com mand but tons for one-click ac cess to many of ten-
used func tions. See the 2700 Se ries User’s Man ual for de tailed in for ma tion.
The Standard Toolbar
The Stan dard toolbar gives you quick ac cess to 2700 se ries file, printer and
ed it ing op er a tions, as well as Sweep Stop/Start and FFT Time/Fre quency do -
main switch ing. See the 2700 Se ries User’s Man ual for de tailed in for ma tion.
The Panels Toolbar
The Panels toolbar gives you quick ac cess to 2700 se ries mea sure ment and
con trol pan els: See the 2700 Se ries User’s Man ual for de tailed in for ma tion.
The Macro Toolbar
The Macro toolbar of fers one-click op er a tions for run ning and ed it ing an
AP Ba sic macro. See the 2700 Se ries User’s Man ual for de tailed in for ma tion.
The 2700 se ries menus Chapter 4: 2700 Series Control Software
Getting Started with Your 2700 Series Instrument 29
