Audio Monitor
All configurations contain an internal loudspeaker and headphone jack for listening
to the generator, analyzer, or digital signal monitor points, including noise and
distortion following analog or digital notch filters or the AES/EBU jitter signal. Use of
the audio monitor does not preclude the use of any measurements.
Power Output Typically 1 Watt.
General/Environmental
Power Requirements 100/120/230/240 Vac (–10%/+6%),
50/60 Hz, 240 VA max.
Temperature Range
Operating +5°C to +40°C.
Storage –40°C to +75°C.
Humidity 90% RH (non-condensing).
Altitude 2000 m.
EMC
30
Complies with 89/336/EEC, IEC 61326-1:
Electrical Equipment for Measurement, Control
and Laboratory Use–EMC Requirements - Part 1:
General Requirements, CISPR 11/22 (class B),
and FCC 15 sub J (class B).
Dimensions
Width 41.9 cm [16.5 inches].
Height 14.6 cm [5.75 inches] bench-top (feet attached)
3U [5.25 inches] rack-mount.
Depth 34.5 cm [13.6 inches].
Weight Approximately 15.4 kg [34 lbs].
Safety Complies with:
73/23/EEC, 93/68/EEC, and EN61010-1 2001
Second Edition, Equipment Class I, Installation
Category II, Pollution Degree 2, Measurement
Category I.
CAN/CSA-C22.2 No 61010.1-4, Safety
Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use, Part
1: General Requirements (with Amendment 1).
UL Std No 61010-1 Second Edition, Equipment
for Measurement Use; Part I: General
Requirements.
General/Environmental Chapter 6: Specifications
Getting Started with Your 2700 Series Instrument 89
30
Emission and immunity levels are influenced by the shielding performance of the connecting cables. The
shield ing per for mance will de pend on the in ter nal de sign of the ca ble, con nec tor qual ity, and the as sem bly
meth ods used. EMC com pli ance was dem on strated us ing Au dio Pre ci sion pn 4155.0117 ca bles for all ports
us ing XLR-type con nec tors, Au dio Pre ci sion pn 4155.0301 ca ble for the Mas ter Clk port, and Pasternack
Model No. PE3067-36 for all remaining ports using BNC-type connectors.
