Front Panel Auxiliary Signals
Gen er a tor Mon i tors
(all units ex cept SYS-2720.)
Chan nel A Buffered ver sion of the chan nel A an a log
gen er a tor sig nal. Am pli tude is typically 2.8 Vpp.
Chan nel B Buffered ver sion of the chan nel B an a log
gen er a tor sig nal. Am pli tude is typ i cally 2.8 Vpp.
Gen er a tor Aux il iary Sig nals
(all units ex cept SYS-2720.)
Sync Out put LSTTL com pat i ble sig nal that is in tended to be
used as a trig ger for sta ble os cil lo scope dis plays.
Trig/Gate In put LSTTL com pat i ble in put, func tional with option
“BUR” only.
An a lyzer Sig nal Mon i tors
(all units ex cept SYS-2720.)
Chan nel A Buffered ver sion of the chan nel A an a log in put
sig nal. Am pli tude is typ i cally 0 Vpp–3.6 Vpp.
Chan nel B Buffered ver sion of the chan nel B an a log in put
sig nal. Am pli tude is typ i cally 0 Vpp–3.6 Vpp.
Read ing Buffered ver sion of the an a log an a lyzer out put
sig nal af ter all fil ter ing and gain stages. Am pli tude
is typ i cally 0 Vpp–3.6 Vpp.
Dig i tal Sig nal Mon i tors
(SYS-2720 & SYS-2722 only. )
Via four 24-bit D/A con vert ers. Func tion mon i tored de pends upon an a lyzer
pro gram loaded; for ex am ple, noise and dis tor tion prod ucts af ter the notch fil -
ter are mon i tored with “DSP Au dio An a lyzer” in its THD+N func tion.
Chan nel 1 Buffered ver sion of the dig i tal chan nel 1 sig nal.
Chan nel 2 Buffered ver sion of the dig i tal chan nel 2 sig nal.
Read ing 1 Dis tor tion of the dig i tal chan nel 1 sig nal.
Read ing 2 Dis tor tion of the dig i tal chan nel 2 sig nal.
Chapter 6: Specifications Front Panel Auxiliary Signals
86 Getting Started with Your 2700 Series Instrument
Figure 63. Monitors
panel.
